Scaffolding in Bangalore | JK Scaffolding

Scaffolding

Product Details

Cup-Lock System

JK Scaffolding offers one of the most reliable and robust Cup-Lock Scaffolding Systems in India, manufactured using premium-quality raw materials sourced from trusted vendors. We provide a comprehensive range of Cup-Lock Systems in various dimensions, sizes, and specifications to meet diverse construction requirements. Customized solutions are also available based on specific client needs. Our Cup-Lock Systems are known for their strength, durability, and superior quality, making them suitable for a wide range of construction applications. We also offer wholesale supply to customers across the market. The different types of Cup-Lock Systems manufactured by us are:

Request a Quote Contact Us

Need immediate support?Call +91 9731167401 or +91 9902385322

Specifications

Name	Size .	Name	Size
Vertical	3	Ledger	0.9
Vertical	2.5	Ledger	1
Vertical	2	Ledger	1.25
Vertical	1.8	Ledger	1.5
Vertical	1.5	Ledger	1.8
Vertical	1.2	Ledger	2
Vertical	1	Ledger	2.5
Vertical	0.9
Vertical	0.5

Technical Details

Cup – Lock Verticals

Verticals are provided with Cup Joints welded at 500mm intervals

Captive mobile top cups are forged to withstand rough handling at site

Bottom Cups are pressed with high Quality Steel

Ends are provided with 150mm long spigot for continuous connections

Verticals are ISO tested MS tubes 40mm medium/heavy outer dia 48.3mm

Cup – Lock Horizontals

Made out of 40MM NB is tested medium / heavy class tubes (48.3mm O.D)

Ledgers/Horizontals have similar forged blade ends

Four horizontals to be fixed in Single operation

To fix Top Cup only a hammer is required

Features & Benefits

Built for Safety, Strength & Reuse

Request Callback

Provides safe access to elevated work areas

Strong and durable construction for enhanced stability

Supports workers, tools, and construction materials

Suitable for residential, commercial, and industrial projects

Easy installation and dismantling

High load-bearing capacity

Improves worker safety and productivity

Reusable and cost-effective solution

Designed for demanding construction environments

Available in various configurations to suit project requirements

Talk to our team

Need Scaffolding for your project?

Share your site requirement and our team will help with the right product size, quantity and quotation support.

Request Callback Send Enquiry

Frequently Asked Questions

Helpful answers for Scaffolding enquiries

Scaffolding is used to provide temporary access and support for workers and materials during construction, maintenance, and repair work.

Scaffolding is widely used in residential, commercial, industrial, and infrastructure construction projects.

Yes, scaffolding components are designed for repeated use across multiple projects.

When properly installed and maintained, scaffolding provides a safe and stable working platform for workers.

Yes, scaffolding systems can be supplied for projects of various sizes and requirements.

We offer a range of scaffolding solutions suitable for different construction and maintenance applications.
